DPS−150DX2N Series

万能飾り千鳥ミシン
for zigzag, Decorative stitching.





Hanyu DPS−150DX2Nミシンは、A・B・C・D 4種類の異なった縫製様式がカムの交換と
用意された専用のゲージの使用により多種の模様縫い、ピンタック縫い、コード押縫いその他の高級飾縫いが
多種多様に簡単に出来る万能飾り千鳥ミシンです。このミシンの使用により、生産の合理化に役立ち付加価値
の高い商品を生みだします。
DPS−150DX2Nミシンは、二本針に製作されております。(上糸2本,下糸1本) 針巾は針株(針止具)
がフリーサイズに出来ておりますので、布地その他の条件で針巾の変更は2o~6o迄自由に選ぶことができます。
又、一本針(右、左何れかの針を中心まで移動させる)の使用も自由に簡単に出来ます。使用針(DB×1)
カムは常に在庫されております。なお、特別の模様カムの御用命も申受けます。

DPS-150DX2N is a multi-purpose zigzag sewing machine for various kind of excellent
stitching including pattern stitching, pin tack and cord press stitching.
A, B, C and D-type of our series are available for five different stitchings by exchanging the cam
and the needle gauge. The five highly efficient models in this series enable you to do truly sophisticated,
beautiful work.
DPS-150DX2N machine is a double needle model. (Upper 2 threads lower 1 thread)
The needle gauge can be changed from 2o〜6oby adjusting the needle clump. Also one
Needle can be removed and the other centered foe single needle work.
Specially designed cams are in stock which can be ordered for particular pattern work.
Needle DB×1 Speed 1500S.P.M.





DPS−150DX2N/A
 1本針ミシンで、レンゲ型ピンタック縫い
ニットブラウス、ジャージ、婦人子供服、ハンドバック

Single needle for rose bud-shaped pin tack titching
used for knitted boluses,jerseys,ladies &children’s clothes and handbags.



DPS−150DX2N/C
 1本針又は2本針
 模様縫い又はシェル型ピンタック縫い

Single or double needle model for pattern stitching and Shell-shaped pin tack stitching.



  DPS−150DX2N/B
1本針ミシンで、コード押縫い
二本又は、一本コードを布地の表裏、又は片面にコードを 縫付ける。
二本コードの場合、コードがクロスにならないように押金
と針板が作られております。
カムの交換により6種類のコードステッチが出来ます。
婦人子供服、イタリアンカラーシャツ

  DPS−150DX2N/B
Single needle model for cord press stitching to sew one or two cords on one or both sides. The achine is equipped with a presser foot and a needle plate to prevent crossing when two cord works is done.
6 kinds of cord stitching possible by changing the cam.
Used for ladies & children’s clothes and Italian collar shirts.




  DPS−150DX2N/C
1本針又は2本針
模様縫い又はシェル型ピンタック縫い
約80種のカムの交換で自由に模様を選ぶ事が出来ます。
シャツ衿、カフス、ガードル、エプロン、ブラウス

  DPS−150DX2N/C
Single or double needle model for pattern stitching
and shell-shaped pin tack stitching. You can select any patterns by using about 80 kinds’ changeable cams. Used for collars, girdles, aprons and blouses.



  DPS−150DX2N/D
 2本針ミシン模様ピンタック縫い
カム交換で直線縫いピンタックから27種類以上の 模様ピンタック縫いが出来ます。又、芯糸を入れるとピンタック縫いも出来ます。
婦人子供服、シャツ等からジーンズ迄
他に、千鳥三巻押え・千鳥ヒダ取り器・千鳥シャーリング押え
シェルタック定規等アタッチメント類も取扱っております。
  DPS−150DX2N/D
Double needle for pattern pin tack stitching. More that 27 kinds of pattern pin tacking possible as well as straight pin tacking by exchanging the cam. Pin tack stitching with centered thread is also possible. Used for ladies & children’s, clothes, shirts and jeans.
Attachments are available for zigzag three-fold presser


HANYU SEWING MACHINE MFG. CO., LTD.
2-14-7 KITA HANYU-CITY SAITAMA-PREF JAPAN 348-0057
TEL:048-561-0258       FAX:048-561-0259
URL:http://www.hanyu-machine.co.jp
E-Mail:info@hanyu-machine.co.jp

羽生ミシン製造株式会社
